Description:
1. High quality UV system, UV power can be adjusted easily by +0.1 on control panel, 1.5~5kw (UV control system is 6KW).
2. Conveyor speed and the distance between the lamp and substrate can be adjusted.
3. Conical holders installed to rotate the products for cylindrical products curing.
4. Well UV light protection, auto unloading system.
5. Excellent curing result, reliable quality, CE standard and easy operation.
Tech-data:
|
Tech-data |
UV450M |
|
max substrate width |
300mm |
|
Max. substrate height |
25-250mm |
|
Diameter of the substrate |
10-150 mm |
|
Max curing speed(pcs/h) |
1500-3000pcs/h |
|
Power supply |
5.8KW |
|
Belt width |
450mm |
|
Measurement |
2400 x 800 x 1880（L x W x H） |
|
Net weight |
300kgs |
