General Description:
1. Easy operation and programmable panel
2. XYR worktable adjustable
3. T-slot, flat with vacuum, round and oval functions available and easy conversion.
4. Printing stroke and speed adjustable.
5. Easy fixture adjustment for conical printing
6. CE standard machines
Tech-data:
|
Parameter \ Item |
S300 |
S400 |
S650 |
S1000 |
|
Max.mesh frame size(mm) |
400*550 |
500*660 |
600*960 |
700*1360 |
|
Max.printing area(width*length/arc) |
Ø 90 280×250mm |
Ø 120 380×300mm |
Ø 200 630×400mm |
Ø 310 980×500 mm |
|
Max.substrate diameter(mm) |
200 |
200 |
300 |
400 |
|
Printing speed:pcs/hr |
1100 |
1000 |
600 |
400 |
|
Power |
110/220V 50/60HZ 40W |
|||
